At EMO Milano 2021, GF Machining Solutions highlights two milling solutions to meet shops’ needs for flexibility and robust performance. For five-axis machining with perfect workpiece roundness, superior surface quality and high material removal rates, the compact Mikron MILL P 800 U S demonstrated mill-turn capabilities with enhanced loading access. For high-precision productivity in three-axis vertical milling, the Mikron MILL P 900 – now available globally with the Heidenhain Touch Numerical Control (TNC) 640 – showed ideal capabilities for the mold and die industry.
With both milling and turning capabilities, the Mikron MILL P 800 U S allows shops to machine components fully on a single machine and eliminate transfer-related part errors, along with stacked tolerances, for enhanced quality of finished parts. This scalable solution is perfectly suited for automation, with a smaller footprint compared to the Mikron MILL P 800 U. This makes it the ideal machine when using two machines or more. It has a maximum loading capability of 1,000 kg (2,204.62 lbs) and is suitable for heavy roughing to fine finishing.
A newly redesigned enclosure provides easy, direct loading access at the back of the compact MILL P 800 U S, with additional robot-ready automation options in front of the machine, giving aerospace, automotive and general industry production a new way to expand production in less floor space. For aggressive material removal on the world’s toughest materials, the latest high-dynamic cutting performance, integrated job and tool management and high-speed spindle design combines with high-tech process security for risk-free machining.
Gantry designs on all MILL P 800 U machines offer robust stability for machining tough materials such as titanium alloys over long periods of milling. Heidenhain TNC 640 and Siemens 840D controls ensure process safety, long tool life and overall production efficiency. Intelligent Spindle Monitoring (ISM) displays spindle vibrations in X, Y and Z axes. This complete picture of spindle movement helps reduce tooling costs, extends the life of the machine, heightens part quality and improves productivity.
All machines in the MILL P 800 U range are rConnect ready. This central communications platform enables manufacturers to maximize their productivity and their control over production. Live Remote Assistance (LRA), process improvement modules, predictive maintenance and machine monitoring improve machine uptime and add more flexibility on the shop floor. LRA allows for customer-authorized remote assistance via real-time connection of machines to GF Machining Solutions. With LRA, either the manufacturer using the system or a GF Machining Solutions technician can conduct remote diagnostics and inspections.
The Mikron MILL P 800 U S will be offered to customers as part of a complete newly designed service package. They can expect a full support with one supplier for the whole cell including automation. On top of that, they will receive extra hours of support, quick access to experts to get the machine on track up to 12 times faster, remote support using the latest digital technologies and advanced diagnostics on the spindle and the robot’s motions. Further advantages for customers include the worldwide spindle exchange service within 24 hours, as well as original parts and upgrade to the latest software, reducing downtime significantly.
The Mikron MILL P 900 – Now available with TNC 640
The new Heidenhain Touch Numerical Control (TNC) 640 on the Mikron MILL P 900 answers customers’ need for greater flexibility. The control’s intuitive, user-friendly interface offers a wide range of functions designed to ensure great reliability. Its touch screen allows the operator to navigate through the control quickly and easily, which ultimately frees up the operator for other value-added tasks. Multiple machine optimization modules and smart machine features increase productivity and reduce energy consumption.
The robust MILL P 900 features a polymer concrete machine base that delivers extreme dynamic stiffness, with the thermal management, contour accuracy and precise positioning to create superior surface finishes. A symmetrical portal design and effective chip management heighten operational efficiency.
To reduce cycle times, the machine packs a high-performance, high-speed 20,000-rpm Step-Tec spindle that delivers 120 Nm of torque. The spindle features an advanced V3D vibration monitoring system with three vibration sensors that visualize spindle performance completely and accurately. An available 36,000 rpm spindle delivers the axial stability to create the superb surface finishes necessary for high-end molds with tight tolerances for finish and size.
The MILL P 900 includes a 30-position tool magazine and automatic tool changer, with a 60-position option available. The tool changers deliver 4.2-second tool changes with a 7.4-second chip-to-chip time. Easy access via a side door enables operators to change out tools with ease.
Available integrated automated pallets handle maximum payloads of 200 kg (440 lbs). Chip-control options, lights-out production capabilities and GF Machining Solutions’ rConnect process-monitoring technology all contribute to optimize overall machine utilization and output on the MILL P 900.
The Mikron MILL P 800 U S is perfectly suited for automation.
With both milling and turning capabilities, the Mikron MILL P 800 U S allows shops to machine components fully on a single machine and eliminate transfer-related part errors, along with stacked tolerances, for enhanced quality of finished parts.
The Heidenhain control, TNC 640, is now available on the Mikron MILL P 900 worldwide.
Profile of GF Machining Solutions
GF Machining Solutions is the world’s leading provider of machine tools, diverse technical solutions and services to manufacturers of precision molds and tooling and of tight-tolerance, precision-machined components. The key segments we serve include the aerospace, automotive, medical, energy, information and communications technology (ICT) and electronics industries. Our extensive portfolio ranges from Electrical Discharge Machining (EDM) solutions, three- and five-axis Milling machines and Spindles, 3D Laser texturing machines, Additive Manufacturing and machines for Laser micromachining to solutions for Tooling, Automation, Software and Digitalization—all backed by unrivaled Customer Services and support. GF Machining Solutions is a globally acting Division of the Georg Fischer Group (Switzerland) and maintains a presence at 50 locations worldwide. Its 3,192 employees generated sales of CHF 725 million in 2020.
